B-LFP48-200E Server Rack Battery – 51.2V 10.24kWh
The B-LFP48-200E Server Rack Battery is a high-capacity 51.2V LiFePO₄ lithium energy storage solution designed for smarter, cleaner energy. With a 10.24kWh capacity, it simplifies power management for modern homes and small businesses, providing efficient energy storage, seamless system integration, and reliable backup power. Ideal for residential solar systems, commercial energy management, and off-grid applications, the B-LFP48-200E supports energy independence while delivering stable, uninterrupted power for a variety of energy storage needs.
Sustainable Living, Powered by BSLBATT
Live Sustainably with the B-LFP48-100E 3U
Designed for residential solar systems, commercial energy management, and light industrial energy storage, the
B-LFP48-200E Server Rack Battery (51.2V 10.24kWh) delivers high-capacity, reliable power to meet diverse energy demands.
Its rack-mounted modular design allows easy installation and scalable expansion, providing dependable backup power,
enhanced solar self-consumption, and a stable, uninterrupted energy supply for modern energy storage applications.
Safety
Cobalt-free LiFePO4 technology with a built-in aerosol fire extinguisher provides enhanced safety and effective
fire risk reduction.
Flexibility
Supports parallel connection of up to 63 units of 48V batteries. The modular design enables easy stacking and
future system scalability.
Reliability
Delivers a maximum continuous discharge of 1C with over 6,000 cycles, ensuring stable, long-term
performance for demanding energy storage applications.
Monitoring
Features remote AOT upgrades, built-in WiFi and Bluetooth, and app-based remote monitoring for simple system
management and real-time performance tracking.
Specifications
Explore the full performance of the B-LFP48-200E Server Rack Battery – 51.2V 10.24kWh. Engineered for reliability,
long service life, and scalable energy storage, this LiFePO4 lithium battery delivers safe, high-capacity, and
efficient power for residential solar systems, commercial energy management, off-grid applications, and backup power.
| Parameter | Details |
|---|---|
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 10.24 kWh |
| Cell & Configuration | 16S2P, Lithium Iron Phosphate (LiFePO₄) |
| Battery Type | Rack-Mounted Lithium Battery |
| Dimensions (L × W × H) | 590 × 483 (442) × 222 mm |
| Weight | 95 kg |
| Cycle Life | > 6,000 cycles @ 25℃ |
| Design Life | > 15 years (25℃ / 77℉) |
| Protection Level | IP20 |
| Expandable Units | Up to 63 units in parallel |
| Warranty | 10 years |
| Certifications | CE, IEC 62619, UN38.3 |
